Injection mortar in cartridge 360 ml

Name: Injection mortar in cartridge 360 ml
Brand: OBO Bettermann
SKU: 7205202

Rend. szám 7205202 | EAN-kód 4012197506735

Termékleírás

Termékleírás

Styrene-free, vinyl ester composite mortar for spread-free anchoring of high loads with threaded anchor rods. Side-by-side (shuttle) cartridge, including one mixing tube FIS MR P, to be worked with the pressing gun, type FIS DM S Pro.

European Technical Assessment for cracked and uncracked concrete, as well as for masonry. Fire protection characteristic values with transile and transverse loads under fire exposure up to 120 minutes.

Installation temperature during processing ‒10 °C to +40 °C.
The injection mortar hasva European Technical Assessment (ETA) for cracked and uncracked concrete, as well as for masonry of full or hollow brick. The mortar is earthquake-proof according to performance category C1 and approved in terms of fire protection for concrete and masonry with the fire -resistance class up to 120 minutes.
The injection mortar is applied with the pressing gun, type VM-P 345 Profi, or with a standard silicone press.

The substrate temperature during processing must be –10 °C to +40 °C (concrete) and the ambient temperature after complete hardening –40 °C to +120 °C (in concrete).

The mortar will keep for at least 18 months if stored in a dark, cool and dry place.

Műszaki adatok

Műszaki adatok

Anyag	tűzgátló habarcs
Átlátszó	nem
Ecsettel	nem
Kikeményítési eljárás	2-Komponenten
Méret	247,1 x 69,8

Ragasztó használata	Bau/Montage
Szállítási forma	Tubus
Szín	szürke / barna
Tartalom	360 ml

Minden típus

Minden típus

Típus		Rend. szám	Mennyiség	Legkisebb eladási egység
FIS V Plus 360 S		7205202	Darab	1 Darab

Tartozék

Rendszertartozékok

Termékek	Típus	Rend. szám	Mennyiség	Legkisebb eladási egység
Anchor rod	FIS A M6x110	7205220	Darab	10 Darab
Anchor rod	FIS A M8x110	7205222	Darab	10 Darab
Anchor rod	FIS A M10x110	7205223	Darab	10 Darab
Anchor rod	FIS A M10x130	7205224	Darab	10 Darab
Anchor rod	FIS A M10x150	7205226	Darab	10 Darab
Anchor rod	FIS A M12x160	7205228	Darab	10 Darab
Anchor rod, rustproof	FIS A M8x110 R	7205230	Darab	10 Darab
Anchor rod, rustproof	FIS A M10x130 R	7205232	Darab	10 Darab
Anchor rod, rustproof	FIS A M12x160 R	7205234	Darab	10 Darab
Injection anchor sleeve for perforated masonry	FIS H 12x85 K	7205240	Darab	10 Darab
Injection anchor sleeve for perforated masonry	FIS H 16x85 K	7205242	Darab	10 Darab
Injection anchor sleeve for perforated masonry	FIS H 16x130 K	7205246	Darab	10 Darab
Injection anchor sleeve for perforated masonry	FIS H 20x85 K	7205248	Darab	10 Darab
Steel cleaning brush	BS Ø8	7205250	Darab	1 Darab
Steel cleaning brush	BS Ø10	7205254	Darab	1 Darab
Steel cleaning brush	BS Ø12	7205256	Darab	1 Darab
Steel cleaning brush	BS Ø14	7205258	Darab	1 Darab
Steel cleaning brush	BS Ø16/18	7205262	Darab	1 Darab
Steel cleaning brush	BS Ø20	7205264	Darab	1 Darab
SDS adapter	SDS M8	7205280	Darab	1 Darab
SDS extension	FIS BV	7205290	Darab	1 Darab
